Harmar Highlander VPL
Harmar Mobility
model: HARVPL[400,600,800,1000,1200,1400]
Additional Images
| Additional Resources | |
Call (859) 494-5235 or click
to learn more about our special offers.
| Your Price | $6,565.00 |
|---|---|
| Regular Price | $8,535.00 |
| Additional Shipping? | Yes |
| *Non-Contiguous U.S. States & Territories - please call for shipping charges. | |
The Highlander II represents a new generation and evolution in Vertical Platform Lifts. New technologies introduced in the Highlander II make this VPL series more reliable, easier to use, easier to service, easier to troubleshoot, and the premiere market choice for platform lift solutions.
Innovation is at the heart of this next generation Vertical Platform Lift. The Highlander II is an outstanding choice for vertical lifting solutions in the home or in light commercial settings where an elevator is impractical or unnecessary.
Features:
Innovation is at the heart of this next generation Vertical Platform Lift. The Highlander II is an outstanding choice for vertical lifting solutions in the home or in light commercial settings where an elevator is impractical or unnecessary.
Features:
- Guardian System: 4 bright, high-contrast LED status lights give continual performance feedback from the lift's control board. Monitoring almost every critical system, Guardian can provide immediate feedback and guidance.
- SteadyDrive: Ensures a smooth, quiet and stable lift.
- ReadyUPS System: True battery back-up option that can deliver at least 5-cycles in the event of power loss.
| Lifting Capacity | 750 lb |
| Standard Lift Height | 53" |
| Maximum Lift Height Upgrade | 171" |
| Arrives Assembled | Yes |
| Drive System | 1" Diameter Acme Screw Drive |
| Optional Drive Systems | None Available |
| Battery Powered Option | Yes |
| Constant Pressure Platform Control | Yes |
| Emergency Stop Platform Control | Included |
| Alarm Button | Optional |
| Keyed Platform Control | Optional |
| Call-Send Controls | One Per Stop Included |
| Optional Call-Send Controls | Keyed and/or Wireless |
| Platform Type | Solid with Non-Skid Coating |
| Platform Size | 36" x 48" (34" Usable Width) |
| Optional Platform Sizes | 36" x 60" (34" Usable), 42"x 54" (34" Usable), 42" x 60" (40" Usable) |
| Platform Configuration | Straight-Thru Access |
| Optional Platform Configurations | Same Side Entry-Exit, 90 Degree Adjacent Access |
| Grab Rail | Included |
| Upper Access Ramp | None Available |
| Upper Landing Gate | Optional |
| Lower Access Ramp | 36" Fixed or Auto-Folding Standard, Optional 42" Fixed or Auto-Folding |
| Guard Panel | 36", Optional 42" |
| Maximum Stops | 3 |
| Lift Speed (FPM) | 10 |
| Other Options | Fire-Rated Doors, Automatic Door Openers |
| Portable | None Available |
| Shipping Info | |
|---|---|
| Shipping Weight | |
| Shipping Length | |
| Shipping Width | |
| Shipping Height | |
Lifting Height
- $0.0053" MAXIMUM LIFT HEIGHTThe top limit switch sets where your lift will actually stop. This can be set up to 53" high.
- $1,170.0077" MAXIMUM LIFT HEIGHTThe top limit switch sets where your lift will actually stop. This can be set up to 77" high.
- $3,690.00101" MAXIMUM LIFT HEIGHTThe top limit switch sets where your lift will actually stop. This can be set up to 101" high.
- $5,850.00125" MAXIMUM LIFT HEIGHTThe top limit switch sets where your lift will actually stop. This can be set up to 125" high.
- $8,010.00149" MAXIMUM LIFT HEIGHTThe top limit switch sets where your lift will actually stop. This can be set up to 149" high.
- $10,170.00171" MAXIMUM LIFT HEIGHTThe top limit switch sets where your lift will actually stop. This can be set up to 173" high.
Application
- $0.00Residential
- $345.00Commercial (adds: Lighted Emergency Stop w/Alarm, Handrail, 42" Platform Panels)
Power Source
- $0.00AC POWERED
- $995.00READYUPS - BATTERY BACKUP - STD.. 2, 12v @ 12ah
- $1,136.00READYUPS - BATTERY BACKUP - PLUS.. 4, 12v @ 12ah
Use Options
- $202.00OUTDOOR USE
- $229.00COLD WEATHER PACKAGE (FOR STANDARD UPS)
- $443.00COLD WEATHER PACKAGE (FOR PLUS UPS)
Tower Orientation
- $0.00TOWER ON THE LEFT
- $0.00TOWER ON THE RIGHT
Number of Stops
- $0.002 STOPS
- $1,029.003 STOPS - INCLUDES 3 CALL/SENDS, 3-STOP PLATFORM CONTROL
Hoistway Installation
- $0.00INSTALLED IN A HOISTWAY
- $0.00NO HOISTWAY
Platform Type (Width, Depth, Height)
- $0.00Select From Options Below
- $0.00[___________36"_High____________]
- $0.00Straight Through (180 Degrees)
- $0.0036 X 48 X 36 STRAIGHT THROUGH PLATFORM
- $0.00[___________42"_High____________]
- $0.00Straight Through (180 Degrees)
- $372.0036 X 54 X 42 STRAIGHT THROUGH PLATFORM
- $736.0036 X 60 X 42 STRAIGHT THROUGH PLATFORM
- $822.0042 X 54 X 42 STRAIGHT THROUGH PLATFORM
- $922.0042 X 60 X 42 STRAIGHT THROUGH PLATFORM
- $0.0090 Degrees
- $736.0036 X 54 X 42 90 Degree LEFT PLATFORM
- $736.0036 X 54 X 42 90 Degree RIGHT PLATFORM
- $1,100.0036 X 60 X 42 90 Degree LEFT PLATFORM
- $1,100.0036 X 60 X 42 90 Degree RIGHT PLATFORM
- $1,193.0042 X 54 X 42 90 Degree LEFT PLATFORM
- $1,193.0042 X 54 X 42 90 Degree RIGHT PLATFORM
- $1,286.0042 X 60 X 42 90 Degree LEFT PLATFORM
- $1,286.0042 X 60 X 42 90 Degree RIGHT PLATFORM
- $0.00Same Side Entry/Exit (0 Degrees)
- $736.0036 X 54 X 42 SAME SIDE ENTRY EXIT PLATFORM
- $1,100.0036 X 60 X 42 SAME SIDE ENTRY EXIT PLATFORM
- $1,193.0042 X 54 X 42 SAME SIDE ENTRY EXIT PLATFORM
- $1,286.0042 X 60 X 42 SAME SIDE ENTRY EXIT PLATFORM
Platform Gate
- $0.00LIFTS 8' AND OVER THAT ARE NOT IN A HOISTWAY REQUIRE A PLATFORM GATE OR AN INTERLOCK FOR A CUSTOMER PROVIDED GATE.
- $0.00NO PLATFORM GATE
- $1,200.00
36 X 42 PLATFORM GATE W/EMI INTERLOCK, LEFT - $1,200.0036 X 42 PLATFORM GATE W/EMI INTERLOCK, RIGHT
- $1,422.0042 X 42 PLATFORM GATE W/EMI INTERLOCK, LEFT
- $1,422.0042 X 42 PLATFORM GATE W/EMI INTERLOCK, RIGHT
Platform Controls
- $0.00Paddle Controls with Emergency Stop Button
- $165.00Emergency Stop Alarm with Lighted Button
Platform Options
- $136.0054" HANDRAIL [FOR RESIDENTIAL INSTALLATIONS]
- $165.0060" HANDRAIL [FOR RESIDENTIAL INSTALLATIONS]
- $100.00Keylocks for Controls
- $136.00CHICAGO KEY UPGRADE FOR KEYED CONTROLS (EACH)
Ramp Type
- $0.0036" AUTO-FOLD RAMP
- $100.0042" AUTO-FOLD RAMP
- $0.0036" FIXED RAMP
- $100.0042" FIXED RAMP
- $229.00Pit, no Ramp (Add Pit Switch below)
Landing Gate
- $1,258.00
36 X 42 LANDING GATE W/EMI INTERLOCK, LEFT - $1,258.0036 X 42 LANDING GATE W/EMI INTERLOCK, RIGHT
- $1,422.0042 X 42 LANDING GATE W/EMI INTERLOCK, LEFT
- $1,422.0042 X 42 LANDING GATE W/EMI INTERLOCK, RIGHT
Landing Gate Call/Send
- $129.00CALL-SEND ROCKER SWITCH FOR LANDING GATE
- $215.00CALL-SEND ROCKER SWITCH W/KEY FOR LANDING GATE
Fire Rated Doors
- $2,915.00
36" FIRE-RATED HOISTWAY DOOR W/EMI INTERLOCK-LH - $2,915.0036" FIRE-RATED HOISTWAY DOOR W/EMI INTERLOCK-RH
- $3,600.0042" FIRE-RATED HOISTWAY DOOR W/EMI INTERLOCK-LH
- $3,600.0042" FIRE-RATED HOISTWAY DOOR W/EMI INTERLOCK-RH
- $3,429.0036" FIRE-RATED HOISTWAY DOOR W/ELECTRIC STRIKE-LH
- $3,429.0036" FIRE-RATED HOISTWAY DOOR W/ELECTRIC STRIKE-RH
- $4,122.0042" FIRE-RATED HOISTWAY DOOR W/ELECTRIC STRIKE-LH
- $4,122.0042" FIRE-RATED HOISTWAY DOOR W/ELECTRIC STRIKE-RH
Automatic Opener
- $2,743.00AUTOMATIC OPENER FOR LANDING GATE
- $2,743.00AUTOMATIC DOOR OPENER FOR FULL DOOR
Interlocks
- $0.00INTERLOCKS BELOW ARE FOR A CUSTOMER PROVIDED DOOR OR GATE.
- $515.00EMI INTERLOCK FOR DOOR/GATE PROVIDED BY OTHERS - LH
- $515.00EMI INTERLOCK FOR DOOR/GATE PROVIDED BY OTHERS - RH
- $1,000.00FLUSH MOUNT ELECTRIC STRIKE FOR METAL DOORS BY OTHERS
- $1,000.00FLUSH MOUNT ELECTRIC STRIKE FOR WOOD DOORS BY OTHERS
- $0.00OTHER INTERLOCK OPTIONS
- $265.00WIRING FOR INTERLOCKS PROVIDED BY OTHERS
- $229.00KEYED DEAD LATCH FOR USE W/FLUSH MOUNT ELECTRIC STRIKE
Call Send Options
- $229.00CALL/SEND STATION CONTROL BOX - TOP/BOTTOM (EACH)
- $305.00KEYED CALL/SEND STATION CONTROL BOX - TOP/BOTTOM (EACH)
- $343.00WIRELESS CALL/SEND CONTROLS FOR 1 LANDING
- $679.00WIRELESS CALL/SEND CONTROLS FOR 2 LANDINGS
- $1,015.00WIRELESS CALL/SEND CONTROLS FOR 3 LANDINGS
Fascia Panels
- $0.00NO FASCIA PANELS
- $100.00FASCIA PANEL; 41" WIDE x 24" TALL
- $143.00FASCIA PANEL; 41" WIDE x 53" TALL
- $129.00FASCIA PANEL; 47" WIDE x 24" TALL
- $200.00FASCIA PANEL; 24" WIDE x 53" TALL
- $208.00FASCIA PANEL: 41" WIDE, CUSTOM CUT TO HEIGHT
- $236.00FASCIA PANEL: 47" WIDE, CUSTOM CUT TO HEIGHT
Additional Options
- $265.00TOWER BRACE WITH BRACKET
- $229.00PHONE JACK
- $229.00EMERGENCY TOWER LIGHT, BACK-UP
- $36.00EXTRA KEYS (EACH)
- $0.00CUSTOM COLOR (ALLOW 6-8 WEEKS)
- $229.00FLOAT LEVEL SWITCHFloat switch stops the unit completely from operating when water gets to a certain level and trips the switch.
- $229.00Pit Switch
Delivery Options
- $539.00FLAT BED AND FORKLIFT DELIVERY
- $125.00Liftgate Service (for 53" only)
- $0.00Pickup at Freight Terminal
